Overview

This Serial OVER IP device servers are designed to make serial devices network-ready in an instant.

The small size of the servers makes them ideal for connecting devices such as card readers and

payment terminals to an IP-based Ethernet LAN. Use the device servers to give your PC software

direct access to serial devices from anywhere on the network.

Features

·Real COM/TTY drivers for Windows and Linux

·Standard TCP/IP interface and versatile operation modes

·Easy-to-use Windows utility for configuring multiple device servers

·Configure by Telnet or web browser

Ethernet Interface

Number of Ports：1

Speed：10/100 BaseT

Connector：8-pin RJ45

Serial Communication Parameters

Data Bits：7、8

Parity：None、Even、Odd、Space、Mark

Flow Control：Hardware、Off

Baudrate：460Kbps

Serial Signals

RS-232：TXD、RXD、RTS、CTS、DTR、DSR、GND

Software

Network Protocols：ICMP、IP、TCP、UDP、DHCP、BOOTP、Telnet

Configuration Options：Web Console、Serial Console、Telnet Console、Windows Utility

   Windows Real COM Drivers：Windows XP/2003/Vista/7 x86/x64

Physical Characteristics

Housing：Metal

Weight：

1 serial：306g

Dimensions：

Without ears：82x114.10x24.54mm（3.228x4.493x0.966 in）

Power Requirements
