Compliant with most standard receiver connector: Futaba, Hitec, Sanwa, GWS etc. Great for truck, Boat, Racing Car, Helicopter and Airplane.

Steering gear definition of three lines:

Dark gray: GND
Red: VCC 4.8-7.2V
Orange line: pulse input

Specifications:

Power Supply: Through External Adapter.

Stable and Shock Proof. - Coreless Motor - Metal Gear - Double Ball Bearing with  Connector Wire, Length 300mm

Dimensions : 40mm x 19mm x 43mm

Weight : 65.2g

Operating Speed : 0.17sec / 60 degrees (4.8V no load)

Operating Speed : 0.13sec / 60 degrees (6.0V no load)

Stall Torque : 13 kg-cm (180.5 oz-in) at 4.8V

Stall Torque : 15 kg-cm (208.3 oz-in) at 6V

Operation Voltage : 4.8 - 7.2Volts

Gear Type: All Metal Gears

Connector Wire: Heavy Duty, 11.81" (300mm)
